Simple State Component

The Simple State component provides a simple state machine. Each state is represented by a name and an array of zero or more entities. The entities are activated upon entering the state and deactivated upon exiting it. A simple state component may be in NullState, which means no state is active.

Provider

O3DE Core (LmbrCentral) Gem

Simple State properties

Simple State component properties

Property	Description	Values	Default
Initial state	The active state when the Simple State component is first activated.	`<None>` or state Name	`<None>`
Reset on activate	If enabled, Simple State component returns to the Initial state when activated, and not the state held before deactivating.	Boolean	`Enabled`
States	An array of states.
States - Name	Defines the name of the state.	String	`New State`
States - Entities	An array of entities that are associated with a state.	EntityId	None

SimpleStateComponentRequestBus

Request Name	Description	Parameter	Return	Scriptable
`GetCurrentState`	Returns the Name of the current state.	None	State: String	Yes
`GetNumStates`	Returns the total number of states.	None	Count: Integer	Yes
`SetState`	Sets the component to a specific state by Name.	State: String	None	Yes
`SetStateByIndex`	Sets the component to a specific state by its index in the States array.	State Index: Integer	None	Yes
`SetToFirstState`	Sets the component to State[0], the first state in the States array.	None	None	Yes
`SetToLastState`	Sets the component to the last state in the States array.	None	None	Yes
`SetToNextState`	Sets the component to the next state in the States array.	None	None	Yes
`SetToPreviousState`	Sets the component to the previous state in the States array.	None	None	Yes

SimpleStateComponentNotificationBus

Notification Name	Description	Parameter	Return	Scriptable
`OnStateChanged`	Notifies listeners that the state has changed.	None	Old State: String, New State: String	Yes

For more information, see Working with the Event Bus (EBus) system.
